6SM56-S-3000-G brushless servomotor used 3.8Nm, 600V, 3000rpm, resolver PN:81868

This 6SM56-S-3000-G brushless servomotor is a 6 pole,

sinusoidally wound motor made by Kollmorgen Seidel

and is fitted with a resolver and a 24V holding brake.

The motor has a 400V winding making it suitable for use with

servo drives providing up to 600Vdc bus voltage.

The motor is rated at 3.8Nm continuous stall torque, IP64/65, Max speed 3000rpm.

Power connections are made via terminal block and resolver connections

via a connector on the motor housing.

Although used, this item has been tested and is fully functional

Please contact us for further information.
